High Pressure Fly Ash Brick Making Machine
Fly ash brick making machine is the production of fly ash autoclaved brick main equipment, fly ash autoclaved brick is fly ash or other slag or lime as raw materials, add lime, gypsum and aggregate, the embryo material preparation, pressing molding, high-efficiency steam Conservation and other technology made.
|
Name / type |
HSY600 |
HSY800 |
|
Mixer Model |
JS750 |
JS750 |
|
Host size |
3300×2610×3750(mm) |
4300×2610×3750(mm) |
|
Molding cycle |
15-20(S) |
15-20(S) |
|
Weight |
25(T) |
31(T) |
|
Host power |
48.7(kw) |
70(kw) |
|
Rated pressure |
31.5(MPA) |
31.5(MPA) |
|
Plant area |
800 (㎡) |
850 (㎡) |
|
PRODUCT |
Specifications |
HSY600 PCS/MOLD |
HSY800 PCS/MOLD |
Molding cycle |
|
SOLID BRICK |
240×115×53 |
30 |
36 |
15-20 S |
|
2 HOLES |
220×105×65 |
28 |
40 |
25-30 S |
|
4 HOLES |
180×80×80 |
28 |
35 |
25-30 S |
|
6 HOLES |
120×180×80 |
21 |
28 |
25-30 S |
|
6 HOLES |
220×150×115 |
18 |
24 |
25-30 S |
Autoclaved fly ash brick machine Production of product strength, up to MU20, a high level of production technology, low energy consumption, products are widely used in building foundation and inside and outside the wall. Fly ash autoclaved brick machine can make great use of fly ash, and can use wet ash. Each production of 1m brick available at least 800kg of fly ash, an annual output of 50 million brick can be used 60,000 tons of fly ash. This undoubtedly saves the land, the protection ecology environment has the vital significance. Autoclaved brick in all parts of China have a certain scale of production, the application has been quite common.
