Brick machine block forming parameters:

Hollow brick 390 × one hundred and ninety × 190 4 bricks / formwork × 8 hours = 5760-7680 pieces
Perforated brick 240 × one hundred and fifteen × 90 14 bricks / formwork × 8 hours = 17280-23040 pieces
Standard brick 240 × one hundred and fifteen × 51 26 bricks / formwork × 8 hours = 37440-49920 pieces
Color floor tile 200 × one hundred × 60 16 bricks / formwork × 8 hours = 20160-23520 pieces
Note: the above output table is the theoretical calculation value. Molding cycle and production volume are related to raw materials and product types
Raw materials for brick machine production:
German technology frequency conversion concrete block forming equipment generally uses stone powder, fly ash, slag, slag, gravel, sand and water as raw materials.

Efficient use of fly ash, slag, stone powder, desulfurization ash, slag, coal gangue, phosphogypsum, tailings sand and other new wall materials, such as autoclaved fly ash brick, autoclaved lime sand brick, aerated concrete products, etc. It is also used in the production of high content fly ash sintered brick, coal gangue sintered brick, stone powder brick, construction waste brick, domestic incineration waste slag brick, waste soil brick and various blocks, comprehensive utilization of desulfurization gypsum in power plant, etc. it is the first choice for large-scale, automatic and modern waste brick production line.

block machine Main Technical Parameters:

Forming method	Vibration compression molding
Vibration frequency	3800-4500
preset pressure	25mpa
Molding cycle	15-20(s)
Exciting force	68KN
Installed capacity	20(kw)
Total Weight	6200（kg）
Exterior specifications	9450×3300×2700(mm)
Pallet specifications	980×560×20(mm)

Using fly ash / tailings sand / desulfurization ash / slag / slag / stone waste / calcium carbide slag / phosphogypsum to make bricks, the waste utilization rate is more than 90%, each line consumes nearly 100000 tons of solid waste per year, with high product quality (strength ≥ 20MPa) and low cost. The main equipment of the production line can produce porous bricks and hollow blocks of different specifications by changing molds.
The production line is also applicable to the production of other autoclaved or sintered wall materials with solid waste as raw materials, such as high content fly ash sintered brick, coal gangue sintered brick, building waste brick, domestic incineration waste slag brick, waste soil brick, various blocks, comprehensive utilization of desulfurization stone paste in power plant, etc.
It adopts crushed stone powder, sand, stone and cement, and can add a large number of industrial wastes such as fly ash, slag, steel slag, coal gangue, ceramsite and perlite.
One machine is multi-purpose, and various specifications of blocks can be produced by changing the mold:
① Perforated brick and hollow block; ② Ceramsite thermal insulation block; ③ Composite thermal insulation concrete block;
The brick machine adopts German frequency conversion technology:
◇ improve the production efficiency and environmental protection by 30%

◇ it can add color fabric cloth device to produce various specifications of color pavement bricks
