.Max. pressing force

13,000   KN

2.Working beam max. stroke

680 mm

3.Distance between lower   plane & working table for working beam

Max.2,040 mm

Min.1,360 mm

4.De-mould cylinder max.   stroke

600 mm

5.Max. de-mould force

2,000   KN

6.Clearance distance between   both columns

1,600 mm

7.Brick-feeding effective   area in the middle frame

1100×860 mm

8.Front & back width of   base table

1200 mm

9.Front & back width of   working beam plane

940 mm

10.Max. feeding depth

320 mm

11.Max. working frequency   (sand-lime brick)

4.3 times/min

12.Main motor power

110 kW

13.Total weight

62 tons
